Black Fiber Optic Terminal Box , 1U SC / FC / ST / LC Rack Mount Splicing Fiber Optic Patch Panel

Model Number : Fiber Optic Terminal Box

Place of Origin : Shenzhen China

MOQ : NO

Price : Contact us for the price

Payment Terms : T/T, Western Union

Delivery Time : 10-15 days upon receipt of payment

Packaging Details : Carton box

Application : FTTH FTTB FTTX Network

Adapter : FC/SC/LC

Working temperature : -40℃〜+ 85℃

Ports : 12 ports

Name : fiber optic termination box

Type : 1U

Contact Now

12 core 1U SC/FC/ST/LC rack mount Splicing Fiber Optic Patch Panel/Termination Box/ODF

Production Details:

Insertion loss		≤0.2dB
UPC return loss		≥50dB
APC return loss		≥60dB
Life of insertion and extraction		＞1000 times
Working temperature		-40℃~+85℃
Relative humidity		≤85%(+30℃)
Atmosphere pressure		70Kpa~106Kpa

The grounding device is isolated with the cabinet, isolation resistance is less than 2x104MΩ/500V(DC); Insulation Resistance≥2x104MΩ/500V.

The withstand voltage between grounding device and cabinet is no less than 3000V (DC)/min, no puncture, no flash-over; U≥ 3000V.

Features:

1. Full modular design, full positive operation
2. Can be mounted on 19-inch standard rack
3. Applicable to ribbon and non-ribbon cable
4. Can be installed by FC, SC, ST and LC and other adapters
5. Easy to operate, perfect protection
6. Set welding and wiring in one, large-scale high-density

Black Fiber Optic Terminal Box , 1U SC / FC / ST / LC Rack Mount Splicing Fiber Optic Patch Panel
