GYXTW Central Loose Tube Steel Outdoor Fiber Optic Cable PSP Enhancing Moisture Proof

Place of Origin : Shenzhen, China

MOQ : NO

Price : contact us for the price

Payment Terms : T/T, Western Union

Delivery Time : 10-15 days upon receipt of payment

Model Number : Fiber Optic Cable

Certification : CE

Packaging Details : Drum

Application : Outdoor,aerial,duct,FTTH,FTTB,FTTX Network

Structure : Central loose tube,PSP,water-blocking

Fiber count : 2-144 cores,12 core

Fiber type : Single mode or multimode fibers

Material : Unitube Light-armored

Strength member : Steel wire strength member

Contact Now

Central Loose Tube Steel Outdoor Fiber Optic Cable PSP Enhancing Moisture Proof

GYXTW Central Loose Tube Steel Outdoor Fiber Optic Cable PSP Enhancing Moisture Proof

Description

Outdoor loose tube cable has the gel-filled design protecting the cable from moisture environment. The gel within the loose-tube construction stops the penetration of water and keeps it away from the fiber. Also, it keeps water from freezing near the fiber at low temperatures which reduces the chance of stress fractures. Fibers are bundled inside a small plastic tube that can protect fibers from outside stresses. Outdoor loose tube cable is often used in conduits, strung overhead or buried directly into the ground.

Application

1.Adapted to Outdoor distribution

2.Suitable for aerial .pipeline laying method

3.Long distance and local area network communication

Technical Parameters:
Cable Type	Fiber Count	Cable Diameter mm	Cable Weight kg/km	Tensile Strength	Crush Resistance	Bending Radius
				Long/Short Term	Long/Short Term	Static/ Dynamic
				N	N/100mm	mm
GYXS/GYXTW-2~12	2~12	8	60	600/1500	300/1000	10D/20D
GYXS/GY XTW-2~12	2~12	8	60	1000/3000	1000/3000	10D/20D
GYXS/GY XTW-14~24	14~24	10	105	1000/3000	1000/3000	10D/20D

Characteristics
· Good mechanical and temperature performance
· High strength loose tube that is hydrolysis resistant
· Special tube filling compound ensure a critical protection of fiber
· Crush resistance and flexibility
· PSP enhancing moisture-proof
· Two parallel steel wires ensure tensile strength
· Small diameter, light weight and friendly installation
· Long delivery length
